CS1-U
CS1-U magnetic switch is used for cylinder position feedback and can be mounted on compatible pneumatic cylinders to detect piston movement.
Key Specifications
| Item | Specification |
|---|---|
| Switch type | Magnetic cylinder switch |
| Sensing method | Magnetic piston detection |
| Output type | Reed switch / common two-wire type |
| Cable length | 2 m typical |
| Application | End-position detection |
| Mounting | Band mount / slot mount depending on cylinder |
Common Models
| Model | Size / Type | Configuration | Typical Use |
|---|---|---|---|
| CS1-U | Standard type | 2-wire output | General cylinder sensing |
| CS1-U-2M | 2 m cable | LED indication optional | OEM machine use |
| CS1-U with band | Band mount | Round cylinder fit | Mini cylinder detection |
| CS1-U slot type | Slot mount | Profile cylinder fit | Assembly automation |
Application Notes
- Suitable for OEM equipment, industrial automation lines, and replacement demand.
- Dimensions, stroke, thread type, voltage, or mounting accessories can be confirmed before quotation.
- Bulk order, private label, and export packing support are available upon request.
Related Products
PDF Download
This downloadable sheet includes the main specifications, model references, and application notes shown on this page.
