TWH and TWM are heavy-duty stopper-cylinder configurations for conveyor and fixture work. Confirm the series platform, actuation, bore, stroke, stopper assembly, buffer and mounting before...
Ordering code matching
Code format
TWH / TWM [bore]X[stroke] [S] [L/K] [F] [PT/G]Published TWH/TWM code layoutTWH 50X30 S K FTWM 50X30 K| ①Platform | ②Actuation | ③Bore / stroke | ④Magnetic option | ⑤Stopper / self-lock | ⑥Port thread |
|---|---|---|---|---|---|
| TWH 20–80 mm; TWM 50 mm. | Double, single, or spring-return form as published. | Use the published platform table. | Blank none; S with magnet. | L/K stopper configuration; F self-lock where published. | Blank PT; G G thread where published. |
TWH and TWM cover a heavy-duty stopper-cylinder platform. TWH spans the published 20–80 mm bore range, while TWM is the 50 mm platform. Select the actuation and stopper assembly first, then match bore, stroke, buffer and mounting.
Product matching reference
TWM is the published 50 mm heavy-duty platform, while TWH covers the wider 20–80 mm range. Confirm the installed platform, actuation, stopper...
