Find your F-GV type
Choose a type; send a model or photo if unsure.
GV40
40mm vacuum gauge ·1/8 port
Request a QuoteSend a Photo — We’ll Help Identify It →
Send the model, quantity and destination. For multiple items, attach a parts list or BOM.
AirTAC sourcing reference•Vacuum Components
SERIESF-GV
AirTAC F-GV Vacuum Pressure Gauges
40mm vacuum gauge with1/8 port,−100–0kPa /−14–0psi scale and G/PT/NPT thread choices. Send...
Official reference
Based on manufacturer documentation
Model support
For model confirmation
Parts lists
Code, photo, or BOM
Availability / lead time
By model and quantity
Sourcing route & inquiry details
40mm vacuum gauge with1/8 port,−100–0kPa /−14–0psi scale and G/PT/NPT thread choices. Send the full F-GV code or gauge photo for a quote.
Know your model? Send it with the quantity for a quote. Not sure? Start with a photo, label or description. We help identify the model and clarify availability and lead time. Mixed parts lists are welcome too.
Request type
AirTAC originalModel matchingChina-source alternative
Gauge model details
Drawings & dimensions
Installation Drawings & Technical Specifications
Compare installed dimensions
GV40 vacuum specification column
Helpful for Model Matching:
- Full F-GV code,quantity and destination
- Vacuum direction and kPa/psi scale
- G/PT/NPT and1/8 port
- 40mm nominal dial;case clearances from drawing
- Match pressure direction,family and complete scale/thread
- Match diameter,port and mounting drawing
Catalogue Technical Specifications
| Medium | Air / Druckluft |
| Nominal dial / port | 40 mm /1/8 |
| Vacuum scale | −100–0 kPa /−14–0 psi |
| Accuracy class | 2.5 |
| Temperature | −20–70°C |
| Shell / core | Stainless steel / brass |
| Reference A / D dimensions | 42 /37 mm |
Common Model Codes & Configurations:Useful for an RFQ
F-GVGV40F-GV4010GF-GV4010P
Technical reference & selection notes
Ordering Codes, Fit Verification & Specifications
Ordering code matching
Match each code segment
Code format
F-GV40 10 [G/P/T]Only GV40 vacuum range publishedF-GV4010GF-GV4010PF-GV4010T| ①–⑥Vacuum gauge code |
|---|
| F-GV +40 nominal diameter+10 maximum−100kPa indication+G/P/T thread:G/PT/NPT;all kPa/psi. |
Read the model code
If the label is incomplete, send the readable parts together with a photo.
F-GV4010PVacuum gauge codeVacuum gauge code
F-GV +40 nominal diameter+10 maximum−100kPa indication+G/P/T thread:G/PT/NPT;all kPa/psi.
About F-GV
F-GV is a vacuum pressure gauge, separate from GV soft-start valves and GS/GF/GU/GP positive-pressure gauges. The published member is GV40:40mm nominal dial,1/8 connection,accuracy class2.5 and−20–70°C. Stainless steel shell,brass core. F-GV4010 uses10 for the−100kPa maximum vacuum indication;the source shows−100–0kPa and−14–0psi. G selects G thread,P PT,T NPT;all use kPa/psi. The drawing gives42mm A case dimension and37mm D reference depth,not a change to the40mm ordering diameter. Confirm vacuum direction,thread and installation clearances. Send full code,quantity and destination or face/connection photo.
Matching Questions
Is F-GV the same as a GV soft-start valve?
No. F-GV4010 is a40mm vacuum pressure gauge. GV200/300/400 soft-start valves are a separate electrically controlled valve family.
Does40 mean the full outside case is40mm?
40 is the ordering dial size. The source drawing lists A42mm and D37mm;use those reference dimensions for installation and confirm the actual thread.
F-GV
Include this series in a project RFQ
F-GV Add other models, quantities, photos, drawings, or a BOM. One request can cover several product groups.
Confirm inspection requirements before quotationSpecify shipping preferenceConfirm timing in the quotationOcean & Rail Available
