LSHLinear Guides27 pagesOCR 77%
Catalog Notes
Dimensions and motion
- 20:20mm
- 25:23mm
- 15mm
- 30:28mm
Pressure and media
- 采用4列钢珠与滚道45°接触角设计，钢珠达到理想的两点接触，可承受来自径向及横向的正反作用力，并且必要时还可施加预压力来增加刚性。
Connection and mounting
- 正面组合X型（45°-45°）弧形滚道槽设计，使其具有自动调心能力，即使安装面有少许误差，也能被滑块内部吸收并保持高精度平滑稳定的直线运动。
Model Patterns
LSHAM6-B-TBBF1F2F3M4M6
Applications
Linear transfer axes and precision motion modules
Compact automation stations with carriage-based guidance
Replacement sourcing when the installed rail code is incomplete
Matching Questions
How should I confirm the right AirTAC LSH Compatible Linear Guide | Replacement Supplier replacement?
Start with the installed label, dimensions, port or mounting details, and any current photo. Use this AirTAC-compatible linear guide reference when...
Can I send photos or partial model codes only?
Yes. These pages are built for compatible or replacement sourcing when only photos, partial codes, or application details are available.
