AirTAC BSAID Double-Rod Locking Cylinder
BSAID is the double-rod locking-cylinder configuration in the BSA family. Confirm both rod ends, lock direction, bore, stroke and installed clearance before RFQ.
For a quote, include the model code, quantity, and destination. A photo or label is useful when the code is incomplete.
Match a BSAI model code
Enter the code from the label. Case, spaces, ×/x, and ordinary hyphens work.
BSAIDStandard Cylinders
Product image reserved
The matching image will be added after model verification.
Part of the BSAI Series family.
View family overview →Ordering code matching
Match each code segment
Code format
BSAID [bore] × [stroke] [S] [mounting] [PT/G]Published BSAI-family code layoutBSAID 80 × 50 S| ①Model | ②Bore (mm) | ③Stroke | ④Options | ⑤Port thread |
|---|---|---|---|---|
| BSAID: Double-rod locking configuration | 32, 40, 50, 63, 80, 100, 125 | Confirm the published stroke table and installed cylinder. | S: magnetic option; mounting and lock-function configuration require confirmation. | Blank: PT; G: G-thread option. |
Technical reference
Drawing and key data
Installation drawing
- Confirm the double-rod BSAID configuration
- Compare both rod ends, bore, stroke and lock direction
- Check clearance at both rod ends
Key data
Model patterns
- BSAID
- BSAID 80 × 50 S
Reference details
- Family: BSA locking cylinder family
- Configuration: Double-rod locking configuration
- Published bores: 32, 40, 50, 63, 80, 100, 125 mm
- Reference drawing: BSAID exterior drawing, PDF page 10
Quick check
What distinguishes BSAID in the BSAI family?
Double-rod locking-cylinder arrangement; both rod ends and the locking function must be checked together.
BSAID
Include this series in a project RFQ
BSAID Add other models, quantities, photos, drawings, or a BOM. One request can cover several product groups.
