AirTAC ACED Double-Rod Compact Cylinder
ACED is the double-rod ACE-family configuration. Send both rod-end details, bore, stroke and mounting geometry for an RFQ.
For a quote, include the model code, quantity, and destination. A photo or label is useful when the code is incomplete.
Match an ACE model code
Enter the code from the label. Spaces and ×/x formats work.
ACEDUltra-Thin Cylinders
Product image reserved
The matching image will be added after model verification.
Part of the ACE Series family.
View family overview →Ordering code matching
Match each code segment
Code format
ACED [bore] × [stroke] [S] [B] [PT/G]Published code layout; optional positions depend on the selected configurationACED 20 × 30 S B [PT]| ①Model | ②Bore (mm) | ③Stroke | ④Options | ⑤Port thread |
|---|---|---|---|---|
| ACED: Double rod | 12, 16, 20, 25, 32, 40, 50, 63, 80, 100, 125 mm | Required travel; compare the published stroke table and installed cylinder. | S: magnetic option; B: male rod-end option. Blank positions follow the published code guide. | Blank: PT; G: G thread option where shown in the code guide. |
Technical reference
Drawing and key data
Installation drawing
- Double-rod arrangement: compare both rod ends with the installed cylinder
- Compare bore, stroke, both rod ends, and mounting geometry
- Check clearance on both sides of the installed cylinder
Key data
Model patterns
- ACED
- Double rod
- ACED 20 × 30 S B [PT]
Reference details
- Family: ACE compact cylinder family
- Configuration: Double rod
- Published bores: 12, 16, 20, 25, 32, 40, 50, 63, 80, 100, 125 mm
- Reference drawing: ACED exterior drawing, PDF page 5
Quick check
What distinguishes ACED in the ACE family?
ACED has rods on both sides. It is structurally different from standard ACE and must be checked against the installed mechanical interfaces.
ACED
Include this series in a project RFQ
ACED Add other models, quantities, photos, drawings, or a BOM. One request can cover several product groups.
