AirTAC TACED Multi-Position Double-Rod Compact Cylinder
TACED combines multi-position motion with a double-rod arrangement in the ACE compact-cylinder family. Send the complete code, positions and both rod-end details for an RFQ.
For a quote, include the model code, quantity, and destination. A photo or label is useful when the code is incomplete.
Match an ACE model code
Enter the code from the label. Spaces and ×/x formats work.
TACEDUltra-Thin Cylinders
Product image reserved
The matching image will be added after model verification.
Part of the ACE Series family.
View family overview →Ordering code matching
Match each code segment
Code format
TACED [bore] × [stroke] [S] [B] [PT/G]Published code layout; optional positions depend on the selected configurationTACED 20 × 30 S B [PT]| ①Model | ②Bore (mm) | ③Stroke | ④Options | ⑤Port thread |
|---|---|---|---|---|
| TACED: Multi-position, double rod | 12, 16, 20, 25, 32, 40, 50, 63, 80, 100 mm | Required travel; compare the published stroke table and installed cylinder. | S: magnetic option; B: male rod-end option. Blank positions follow the published code guide. | Blank: PT; G: G thread option where shown in the code guide. |
Technical reference
Drawing and key data
Installation drawing
- Multi-position double-rod configuration: compare both rod ends
- Check the required positions, bore, travel, and mounting geometry
- Confirm clearance at both rod ends
Key data
Model patterns
- TACED
- Multi-position, double rod
- TACED 20 × 30 S B [PT]
Reference details
- Family: ACE compact cylinder family
- Configuration: Multi-position, double rod
- Published bores: 12, 16, 20, 25, 32, 40, 50, 63, 80, 100 mm
- Reference drawing: TACED exterior drawing, PDF page 5
Quick check
What distinguishes TACED in the ACE family?
TACED has both multi-position motion and a double-rod construction. Its mechanical interfaces and required positions must be checked together.
TACED
Include this series in a project RFQ
TACED Add other models, quantities, photos, drawings, or a BOM. One request can cover several product groups.
